Shanqi Delong F3000 Dump Truck

Drive form: 8X4
Wheelbase: 1800+4975+1400mm Engine: Weichai WP13NG430E61
Gearbox: Fast 12 gears Rear axle ratio: 5.92
Body length: 11.85 meters Body width: 2.55 meters
Body height: 3.6 meters Front track: 2011/2011mm
Rear track: 1860/1860mm Vehicle weight: 15.5 tons
Rated load: 15.37 tons Total mass: 31 tons
Tonnage level: Heavy truck Approach angle: 16 degrees
Departure angle: 25 degrees Origin: Xi'an, Shaanxi
Market Segment: Road Transport Version: Road Plus

Engine
Engine model: Weichai WP13NG430E61 Engine brand: Weichai
Number of cylinders: 6 Fuel type: Natural gas (LNG/CNG)
Displacement: 12.54L Emission Standard: China VI
Maximum horsepower: 430 horsepower Maximum output power: 316kW
Torque: 2200N·m Maximum torque Speed: 1100-1300rpm
Rated speed: 1900rpm Engine type: SPI+ER+EGR+TWC

Cargo parameters
Cargo box length: 8.8 meters Cargo box width: 2.35 meters
Cargo box height: 1.5 meters Cargo box form: Back-turning self-unloading type

Cab parameters
Cab suspension: Four-point airbag suspension Driver's seat form: Airbag shock-absorbing seat

Gearbox
Gearbox model: Fast 12 gear Gearbox brand: Fast
Forward gears: 12 gears Reverse gears: 2

Shell material: aluminum shell

Tire
Tire specification: 11.00R20 18PR, 12.00R20 18PR, 12R22.5 18PR Number of tires: 12

Chassis
Frame height: (970-850)×320(8+7+8)mm Front axle description: 9.5T MAN
Front axle allowable load: 6500/6500kg Rear axle description: 16T MAN double stage
Rear axle allowable load: 18000 (two-axle group) kg Speed ratio: 5.92
Number of springs: 3/3/5,10/10/10,14/14/12,10/10/12

Control configuration
ABS anti-lock brake: ●

Internal configuration
Air Conditioning Adjustment Type: Automatic Electric Windows: ●

Brake safety
Electronic central locking: ●
